Show Translation property of class AffineTransform



This section shows you the Translation property.

To show translation, we have used Ellipse2D class to draw the oval. The method getTranslateInstance() returns the translation transformation. Following code move the origin to (100,100):







AffineTransform affineTransform = AffineTransform.getTranslateInstance(100, 100);
g2d.transform(affineTransform);

The method draw(shape) draws the specified shape in the original location defined.

Following code transform the Graphics2D:

g2d.transform(AffineTransform.getTranslateInstance(200, 0));

The stylistic representation of the outline for the specified shape has been given by the interface Stroke. To outline the graphics primitives, which are rendered with an object of Graphics2D, we have used the BasicStroke class, which defines a set of rendering attributes. The BasicStroke.CAP_BUTT gives the dash segments. The BasicStroke.JOIN_BEVEL joins the path segments by connecting the outer corners of their wide outlines with a straight segment.

 Following code draws the specified shape in dashed format:

Stroke stroke = new BasicStroke(1, BasicStroke.CAP_BUTT,
BasicStroke.JOIN_BEVEL, 0, new float[] { 2, 1 }, 0);
g2d.setStroke(stroke);
g2d.draw(shape);

The method setStroke() sets the stroke settings for the Graphics2D context, when you draw the shape.

Here is the code of TranslationWithTransform.java

import java.awt.*;
import javax.swing.*;
import java.awt.geom.*;

public class TranslationWithTransform extends JComponent {
  Shape shape;
  public TranslationWithTransform() {
  shape = create();
  }
private Shape create() {
  float num = 100 2.00f;
  return new Ellipse2D.Float(num, num, * num, num);
  }
  public void paint(Graphics g) {
  Graphics2D g2d = (Graphics2D) g;
  AffineTransform affineTransform = AffineTransform.
   getTranslateInstance(
100100);
  g2d.transform(affineTransform);
  g2d.setPaint(Color.red);
  g2d.draw(shape);
  g2d.transform(AffineTransform.getTranslateInstance(2000));
  Stroke stroke = new BasicStroke(1, BasicStroke.CAP_BUTT,
  BasicStroke.JOIN_BEVEL, 0new float[] { 2}, 0);
  g2d.setStroke(stroke);
  g2d.draw(shape);
  }
  public static void main(String[]args) {
  JFrame frame = new JFrame("Shows Translation");
  frame.getContentPane().add(new TranslationWithTransform());
  frame.setSize(520250);
  frame.setVisible(true);
  }
}

Output will be displayed as:

Download Source Code
